4.0" Bore x 1.75" Rod Cylinder Hydraulic Log Splitter Cylinder Rebuild Seal Kit
Feature:
- Made of high quality material, durable and practical to use.
- High Performance, Long Working Life.
- Easy installation and removal.
- Professional install will be highly recommend. Installation instruction not included.
- Designed and manufactured to exacting specifications which meet or exceed OEM performance.
Specifics:
Basic Information
- Condition: 100% Brand New
- Material: Rubber Plastic
- Type: Cylinder Seal Kit
- Seal Size: 4.0" Bore x 1.75"
- Fitment Type: Direct Replacement
Detailed Components
1. Cylinder tube Bore (I.D.) 4.0" x rod (O.D) 1.75". Please note some cylinder rod head OD size is not rod size.
2. Wear rings
Piston wear ring: 101.6 mm (OD 4") x 95.25 mm (ID 3.75") x 9.53 mm (0.375" wide), Nylon
Rod wear ring: 44.5 mm (ID 1.752") x 50.8 mm (OD 2") x 9.53 mm (0.375" wide), Nylon
3. Piston seals
1 square ring and 1 O-ring. Piston Square ring: D101.6 mm x 91.6 mm x 3.28 mm; O-ring (installed under the square ring): 91.0 mm x 2.65 mm. CPU + NBR
4. Rod O-ring (item 13): 44.5 mm x 54 mm x 5 mm, CPU. There is O-ring inside.
5. Rod dust ring (Item 12): 44.5 mm x 54 mm 5.5 mm / 7.3 mm, TPU
OEM Cylinder Specifications (4.0" Bore x 1.75" Rod)
- Retracted (center to center between rod mountain hole and clevis hole): 32.4"
- Extended (center to center same as above): 56.4"
- Stroke: 24 ± 0.05"
- Dimension from center of clevis hole to back face of cylinder: 2.95"
- Dimension from center of rod end hole to front face of rod: 1.06"
- Dimension from center of rod end hole to front face of cylinder: 1.18"
- Ports: 1/2" NPT
- Dimension from port to port: 25.4"
- Rod: 1.75" rod
- Rod end mountain hole: 0.55"
- Clevis Mountain hole: 1.16"
- Dimension between mountain clevis to clevis: 0.87"
- Thickness of each mountain clevis: 0.375"
- Length of each mounting clevis: 4.125"
Important Notes:
- Please allow 1-3 mm difference due to manual measurement.
- Please be aware this part is not an original part; it is an aftermarket part.
- Before you purchase, please confirm whether it is suitable for your needs.
Package Included:
- 1 x Cylinder Seal Kit
Shipping Information:
Free Quick Shipping to USA.
Estimated Time of Arrival: within 3-8 working days.
Warranty:
- Customers have the right to request a return within 60 days from the date of product receipt.
- At Itopteng, we offer prompt customer service to assist with product usage inquiries and facilitate returns or refunds.
